2025 ZT Elite - Spindle & Deck Idlers

2025 ZT Elite - Spindle & Deck Idlers

The 2025 ZT Elite Spindle & Deck Idlers system plays a key role in maintaining blade rotation and belt efficiency. At BadBoyMowerParts.com, we stock high-quality Bad Boy Mower Parts, including replacement spindles, idler pulleys, tensioners, and securing hardware to keep your mower cutting smoothly. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements for durability and reliability. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct spindle and idler components for easy installation. A well-maintained spindle and idler system reduces vibration, enhances blade speed, and extends belt life. We offer Bad Boy Parts Online for quick replacements and fast shipping. Plus, with Free Shipping On Orders Over $100, maintaining your 2025 ZT Elite Spindle & Deck Idlers is now more affordable. Order today for optimal cutting performance and extended component lifespan.

Bad Boy Mower Parts Lookup

2025 ZT Elite - Spindle & Deck Idlers
  Position Number SKU Product Title Price
5.1 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
5 037-6017-50 037-6017-50 - Compact Outlaw / Maverick / Walkbehind / ZT & 2007 Pup Aluminum Spindle Housing (obsolete)
use part #037-6015-50
$199.99
6 037-6029-00 037-6029-00 - Spindle Bearing (See Models Used On For Details)
$42.58
7 037-6026-00 037-6026-00 - Short Spindle Shaft - No Grooved Shaft
$83.77
8 037-8002-00 037-8002-00 - Dust Cover (Used on 037-4000-00 & 037-6015-50)
$11.76
9 037-8050-00 037-8050-00 - Tube Spacer For Spindle Shaft - Small Spindle
$8.69
10 037-9050-00 037-9050-00 - Collar Spacer - Top of Spindle (See Models Used On For Details)
$7.28
11 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
12 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
13 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
14.1 039-2127-17 039-2127-17 - Deck Hanger Assy. (See Models Used On For Details)
$15.60
14 039-2127-00 039-2127-00 - Deck Hanger (See Models Used On For Details) (obsolete)
use part #039-2127-17
$15.60
15 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
16 018-0067-00 018-0067-00 - 1/2-13 x 3 Carriage Bolt
$3.29
17 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
18 033-8050-00 033-8050-00 - 2017-2025 5" Split Idler Pulley-Tensioner Only
$35.48
19 039-0401-00 039-0401-00 - Small Belt Retainer
$5.49
