2025 ZT Elite - Pump Idler & Deck Height

2025 ZT Elite - Pump Idler & Deck Height

The 2025 ZT Elite Pump Idler & Deck Height system ensures smooth deck adjustments and optimal mower performance. At BadBoyMowerParts.com, we provide premium Bad Boy Mower Parts, including pump idlers, adjustment levers, height control brackets, and mounting hardware for seamless operation. Our Bad Boy Lawn Mower Parts inventory offers factory-grade replacements designed for long-term use. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the necessary pump idler and deck height components for easy installation. Proper maintenance enhances cutting accuracy, reduces strain on belts, and extends mower life. We stock Bad Boy Parts Online for fast replacements and hassle-free ordering. Plus, with Free Shipping On Orders Over $100, keeping your 2025 ZT Elite Pump Idler & Deck Height system in top condition is now more affordable. Order today for precise cutting and efficient mower operation.

Bad Boy Mower Parts Lookup

2025 ZT Elite - Pump Idler & Deck Height
  Position Number SKU Product Title Price
1A 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
1 017-9077-00 017-9077-00 - Pillow Block-Male
$21.28
2 017-9079-00 017-9079-00 - Pillow Block-Metal Plate
$21.28
7 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
8 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
9 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
10 026-1100-00 026-1100-00 - 2017-Newer CAM Plate Use With Deck Adjuster (See Models Used On For Detail)
$15.55
11A 028-0070-17 028-0070-17 - Deck Height Bar Assy. (See Models Used On for Details)
$29.66
11 028-0014-00 028-0014-00 - Deck Height Dial Rod (See Models Used For Detail)
$31.17
23 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
24 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
25 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
26 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
27 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
28 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
29 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
30A 039-5944-01 039-5944-01 - Pump Idler Bracket Assy (See Models Used On For Details)
$62.46
30 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
