2025 ZT Elite - Upper Frame

2025 ZT Elite - Upper Frame

The 2025 ZT Elite Upper Frame provides critical structural support, ensuring durability and stability. At BadBoyMowerParts.com, we provide top-quality Bad Boy Mower Parts, including frame reinforcements, mounting brackets, bolts, and securing hardware to maintain mower strength. Our Bad Boy Lawn Mower Parts inventory offers factory-grade replacements designed for long-term use. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct upper frame components for easy installation. A well-maintained upper frame improves stability, prevents vibrations, and extends mower lifespan. We stock Bad Boy Parts Online for quick replacements and fast shipping. Plus, with Free Shipping On Orders Over $100, maintaining your 2025 ZT Elite Upper Frame is now more affordable. Order today to ensure maximum durability and long-lasting performance.

Bad Boy Mower Parts Lookup

2025 ZT Elite - Upper Frame
  Position Number SKU Product Title Price
1 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
2 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
3 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
4 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
5 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
6 014-8047-00 014-8047-00 - Rubber Cap Cover
$2.99
7 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
8 018-2012-00 018-2012-00 - 1/4-20 X 1/2 BS C/S 18-8 SS
$2.99
9 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
10 018-8066-00 018-8066-00 - 5/16 x 7/8 Carriage Bolt
$2.99
11 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
12 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
13 026-1016-00 026-1016-00 - Seat Plate
$102.11
14 029-4011-00 029-4011-00 2023 Floorboard Rubber Bumpers
$2.99
15 034-8045-03 034-8045-03 - Seat Spring Assembly (See Models Used On For Detail)
$32.09
16 034-8045-22 034-8045-22 - 2022 Mav/HD seat spring assembly with st
$32.09
18 064-3050-21 064-3050-21 - 2021-2025 Load Balanced Brake Cable 1
$56.77
19 064-3051-21 064-3051-21 - 2021-2025 Load Balanced Brake Cable 2
$56.77
20 069-1051-21 069-1051-21 - Load Balanced Brake Handle Assembly
$70.97
22 071-2101-00 071-2101-00 - 2021-2024 ZT Elite Seat
$625.99
23 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
25 086-3600-00 086-3600-00 - Wiring Harness With Clips (See Models Used On For Details)
$299.99
28 091-0021-00 091-0021-00 - Steering Control Sticker
$11.76
29 091-0339-18 091-0339-18 - Brake Decal (See Models Used On For Details)
$11.76
30 091-3017-00 091-3017-00 - Pump Belt Route Decal
$4.92
31 091-3150-00 091-3150-00 - Outlaw Warning Decal (See Models Used On For Details)
$10.91
32 091-4063-00 091-4063-00 - Flying Bulldog Front Bumper Decal
$12.83
