2012 CZT - Battery & Frame

2012 CZT - Battery & Frame

Introducing the 2012 CZT Battery & Frame, a robust assembly designed to provide reliable power and structural integrity for your mower. This component integrates a high-capacity battery with a durable frame, ensuring consistent performance and longevity. Engineered using quality materials and advanced techniques, the Battery & Frame assembly delivers efficient energy storage and a secure mounting system that withstands daily demands. Its design facilitates easy installation and maintenance, reducing downtime and improving reliability. This integrated assembly supports the CZT’s electrical and mechanical systems, ensuring optimal performance in residential and commercial applications. For detailed schematics, verified components, and expert support, please consult Bad Boy Mower Part diagrams, Bad Boy Mower Parts, Bad Boy Lawn Mower Parts, Bad Boy Parts Online and Free Shipping On Orders Over $100 available on our website. Visit BadBoyMowerParts.com for guidance and advice. Upgrade your mower with this assembly to achieve dependable power and stability every time. Enjoy excellence today. Achieve peak performance every single day.

Bad Boy Mower Parts Lookup

2012 CZT - Battery & Frame
  Position Number SKU Product Title Price
1 070-5400-00 070-5400-00 - 2011-2012 CZT, 2012 ZT Frame
$1299.99
2 067-8080-00 067-8080-00 - ZT Hydraulic Tank and Cap (See Models Used On For Details)
$49.21
3 066-5050-00 066-5050-00 - Hydraulic Tank Cap (See Models Used On For Details)
$15.60
4 030-7040-00 030-7040-00 - 1/4 x 1 Hex Head Tek Screw
$2.99
5 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
6 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
7 072-8066-00 072-8066-00 - 1/2" Hose Clamp
$2.99
8 108-5349-00 108-5349-00 - Solenoid (See Models Used On For Detail)
$29.41
9 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
10 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
11 064-5301-00 064-5301-00 - 12" Red Battery Cable
$17.16
12 103-5300-00 103-5300-00 - Red Lug Boot
$5.82
14 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
17 064-5300-00 064-5300-00 - 24" Red Battery Cable
$21.85
18 064-8061-00 064-8061-00 - 30 Black Battery Cable (See Models Used On For Details)
$22.92
19 018-8059-00 018-8059-00 - 5/16-18x1-3/4 Hex Bolt
$2.99
20 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
21 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
22 039-5944-98 039-5944-98 - Pump Idler Assembly (obsolete)
use part #039-5944-01
$62.46
23 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
24 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
25 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
26 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
27 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
28 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
29 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
30 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
31 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
32 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
33 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
34 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
35 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
36 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
37 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
39 026-0054-00 026-0054-00 -Rear Plate (See Models Used On For Details)
$179.99
40 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
41 031-0060-00 031-0060-00 - 2012-2016 CZT/ZT, 2016-2018 Maverick, 2016-2021 Compact Outlaw Neutral Lever/Rod
$14.19
42 044-2004-00 044-2004-00 - Bow Pin
$2.99
43 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
45 026-0052-00 026-0052-00 -Pump Cover Plate (See Models Used On For Details)
$83.77
46 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
47 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
48 084-4015-00 084-4015-00 - Rubber Trim
$10.99
49 014-3000-00 014-3000-00 - Square 3/4" Plug-SQR07-1620 ZT Fan Cover
$2.99
50 018-4705-00 018-4705-00 - - 5/16-18 X 3 Hex Bolt Zinc Fully Threaded
$2.99
53 069-8055-00 069-8055-00 - Brake Plunger Stop
$5.82
54 026-0060-00 026-0060-00 - CZT Rear Cover (See Models Used On For Details)
$179.99
