2013 MZ Magnum - Blade Assembly

2013 MZ Magnum - Blade Assembly

The 2013 MZ Magnum Blade Assembly is an essential part of the mower, providing precise cutting for a clean, even lawn. Over time, the blades can wear down, requiring replacement. Bad Boy Mower Parts offers high-quality replacement blade assemblies that fit perfectly with your 2013 MZ Magnum. These parts are designed to meet the original equipment standards, ensuring optimal performance. Bad Boy Lawn Mower Parts offers a selection of blades that are durable and efficient, ensuring your mower maintains its cutting power. With the help of Bad Boy Mower Part diagrams, you can easily locate the blade assembly part you need. Shopping Bad Boy Parts Online means you can access a variety of blade options, and with Free Shipping On Orders Over $100, you get added value on every purchase. Visit BadBoyMowerParts.com for the best selection of blade assemblies for your mower.

Bad Boy Mower Parts Lookup

2013 MZ Magnum - Blade Assembly
  Position Number SKU Product Title Price
1 037-2000-00 037-2000-00 - Spindle Assembly fits All ZT Avengers and MZ/MZ Magnum Also Fits 2016-2022 36" Stand-On
$204.33
2 033-4820-00 033-4820-00 - Spindle Pulley - 42"/48" MZ/MZ Magnum, 34"/36" Revolt/Revolt SD
$31.22
3 042-0010-00 042-0010-00 - 3/16 X 1 Square Machine Key
$4.81
4 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
5 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
6 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
7 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
8 038-4826-00 038-4826-00 - 48" High Lift Fusion Blade-MZ
$22.99
9 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
10 037-6025-00 037-6025-00 - Spindle Shaft - All MZ/MZ Magnum & 2016-2022 Stand-On (36" Deck)
$60.98
11 037-6024-00 037-6024-00 - All MZ Models & 2016-2022 Stand-On (36" Deck) Spindle Bearing
$34.35
12 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
13 038-0005-00 038-0005-00 - 54" MZ High Lift Fusion Blade
$22.99
