2010 Pup and Lightning - Clutch Stack

2010 Pup and Lightning - Clutch Stack

The 2010 Pup and Lightning Clutch Stack plays a critical role in engaging and disengaging the mower blades, ensuring smooth performance. At BadBoyMowerParts.com, we provide premium Bad Boy Mower Parts, including clutch plates, pressure plates, bearings, and mounting hardware for maximum durability. Our Bad Boy Lawn Mower Parts inventory ensures factory-quality replacements designed for efficiency and reliability. Using our Bad Boy Mower Part diagrams, you can easily find and order the correct clutch stack components for hassle-free installation. Routine maintenance prevents slippage, enhances engagement speed, and extends the lifespan of your mower’s clutch system. With access to Bad Boy Parts Online, ordering replacement clutch parts is simple and convenient. Plus, with Free Shipping On Orders Over $100, maintaining your 2010 Pup and Lightning Clutch Stack is now more affordable. Order today to ensure smooth blade engagement, improved efficiency, and long-lasting clutch performance.

Bad Boy Mower Parts Lookup

2010 Pup and Lightning - Clutch Stack
  Position Number SKU Product Title Price
1 070-1000-00 070-1000-00 - PTO Clutch (See Models Used On For Details)
$279.99
2 033-5034-00 033-5034-00 - 4 3/4 Motor Pulley - DB74-601 Comes with set screw only. Keyway IS NOT included. (See Models Used On For Details)
$35.48
3 019-6029-00 019-6029-00 - 1.140x1.750x.132 Flat Washer
$2.99
4 025-5000-00 025-5000-00 - 1.125 ID X 1.750 OD X.625 THK Spacer Zinc
$7.69
5 025-6000-00 025-6000-00 - 1 1/8 x.910 Spacer (Clutch)
$12.77
6 018-5300-00 018-5300-00 - 7/16-20 X 2-1/2 Hex Bolt
$2.99
7 019-8053-00 019-8053-00 - 7/16 Lockwasher zinc
$2.99
8 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
9 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
10 018-5028-00 018-5028-00 - M10 X 1.5 X 60MM
$2.99
