2012 Outlaw & Outlaw Extreme - Deck Lift Assembly

2012 Outlaw & Outlaw Extreme - Deck Lift Assembly

The 2012 Outlaw & Outlaw Extreme Deck Lift Assembly is a critical component of your mower that allows you to easily adjust the deck height. Whether you’re replacing a worn-out lift assembly or upgrading to improve performance, BadBoyMowerParts.com has all the necessary Bad Boy Mower Parts for your needs. Our Bad Boy Mower Part diagrams ensure that you can find the right lift assembly and its corresponding components quickly. We offer a wide range of Bad Boy Lawn Mower Parts, so you can choose the best parts for your mower’s performance. Ordering Bad Boy Parts Online is fast and easy, and our streamlined website ensures a hassle-free experience. Plus, with Free Shipping On Orders Over $100, you won’t have to worry about shipping costs when ordering your parts. Keep your 2012 Outlaw & Outlaw Extreme mower running smoothly by replacing your deck lift assembly with high-quality parts from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2012 Outlaw & Outlaw Extreme - Deck Lift Assembly
  Position Number SKU Product Title Price
1 070-5350-00 070-5350-00 - 2012-2014 Outlaw/Outlaw Extreme Frame
$1299.99
2 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
3 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
4 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
5 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
6 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
7 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
8 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
9 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
11 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
12 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
13 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
14 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
15 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
16 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
17 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
18 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
19 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
20 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
21 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
22 028-6020-00 028-6020-00 - Rear Actuator Bar Assy (See Models Used On For Detail)
$106.48
23 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
25 028-6050-00 028-6050-00 - Outlaw Deck Linkage Rod
$28.39
26 017-7008-00 017-7008-00 - 1" Pillow Block Bearing (See Models Used On For Details)
$21.29
27 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
28 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
30 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
32 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
33 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
34 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper (See Models Used On For Details)
$4.83
35 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
36 026-2110-00 026-2110-00 - Outlaw Rear Plate
$199.99
37 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
38 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
39 072-8067-00 072-8067-00 - 5/8 Hose Clamp SS
$2.99
40 051-9000-00 051-9000-00 - 5/8 Braided Hose Priced per Foot
$4.81
41 066-5050-00 066-5050-00 - Hydraulic Tank Cap (See Models Used On For Details)
$15.60
42 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
43 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
44 067-8085-00 067-8085-00 - Expansion Tank for Outlaw (See Models Used On For Details)
$31.22
45 029-7037-00 029-7037-00 - 14" Bumper
$42.79
46 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
47 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
48 026-0013-00 026-0013-00 - 2010-2018 Outlaw & 2012-2018 Compact Diesel Deck Lift Pedal
$21.28
49 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
50 201-1050-00 201-1050-00 - Spoiler Support Right
$35.48
51 201-1051-00 201-1051-00 - Spoiler Support Left
$35.48
52 026-1040-00 026-1040-00 - Outlaw Spoiler Plate
$106.99
53 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
54 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
55 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Deck Damper
$62.40
56 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
