2010 ZT - Drive Arms

2010 ZT - Drive Arms

The 2010 ZT Drive Arms play a crucial role in controlling mower movement, ensuring smooth and responsive handling. At BadBoyMowerParts.com, we supply high-quality Bad Boy Mower Parts, including drive arms, mounting brackets, bushings, and hydraulic components for optimal performance. Our Bad Boy Lawn Mower Parts inventory guarantees factory-quality replacements built for durability and efficiency. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct drive arm components for easy installation. Routine maintenance prevents excessive wear, enhances maneuverability, and extends the lifespan of your mower’s drive system. With access to Bad Boy Parts Online, ordering replacement drive arm components is quick and simple. Plus, with Free Shipping On Orders Over $100, maintaining your 2010 ZT Drive Arms is now more affordable. Order today to ensure smooth operation, precise control, and reliable movement for all your mowing tasks.

Bad Boy Mower Parts Lookup

2010 ZT - Drive Arms
  Position Number SKU Product Title Price
1A 031-9060-18 031-9060-18 - Adjustable Steering Arm Kit
$178.99
1 031-8851-98 031-8851-98 - OBSOLETE USE Part # 031-8851-70 Right Steering Arm Assembly Gold Elbow (See Models Used On For Details) (obsolete)
use part #031-8851-70
$93.64
2 031-8850-98 031-8850-98 - OBSOLETE USE Part # 031-8850-70 Left Steering Arm Assembly Gold Elbow (See Models Used On For Details) (obsolete)
use part #031-8850-70
$93.64
3 027-9001-00 027-9001-00 - 2010-2012 ZT/CZT, 2010-2016 MZ/MZ Magnum Drive Arm Lever Housing (Right)
$42.58
4 027-9000-00 027-9000-00 - 2010-2012 ZT/CZT, 2010-2016 MZ/MZ Magnum Drive Arm Lever Housing (Left)
$42.58
5 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
6 018-8063-00 018-8063-00 - 5/16-18 X 3/4 Hex Bolt
$2.99
7 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
8 034-8025-00 034-8025-00 - Drive Lever Housing Spring
$4.07
9 032-8024-00 032-8024-00 -.502x.618x.500 Spacer Nylon Drive Arm Block
$2.99
10 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
11 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
12 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
13 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
15 069-4007-00 069-4007-00 - Rubber Steering Arm USE 069-4010-00 (obsolete)
use part #069-4010-00
$8.12
16 099-6046-00 099-6046-00 - Ball Joint - 3/8-24 (See Models Used On For Details)
$12.83
17 099-2009-00 099-2009-00 - Quick Release Ball Joint (See Models Used On For Details)
$9.89
18 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
19 035-5400-00 035-5400-00 - 2007-2012 CZT/ZT Right Steering Push Rod
$30.87
20 035-5401-00 035-5401-00 - 2007-2012 CZT/ZT Left Steering Push Rod
$30.87
21 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
