2013 Diesels - Frame (Compact Diesel)

2013 Diesels - Frame (Compact Diesel)

The 2013 Diesels Frame (Compact Diesel) provides the sturdy foundation your mower needs to support the engine and other key components. If you're in need of replacement or repair parts for your frame, BadBoyMowerParts.com has everything you need. We carry a full range of Bad Boy Mower Parts for the 2013 Diesels Frame (Compact Diesel), from structural components to mounting hardware. With our Bad Boy Mower Part diagrams, finding the right parts for your frame is easy. Our extensive inventory of Bad Boy Lawn Mower Parts ensures that you’re getting only the best parts for durability and performance. Ordering Bad Boy Parts Online is convenient, and you can take advantage of Free Shipping On Orders Over $100. Ensure your mower stays in excellent condition by choosing the right frame parts from our selection. Visit us today to get everything you need for your 2013 Diesels compact diesel model.

Bad Boy Mower Parts Lookup

2013 Diesels - Frame (Compact Diesel)
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 070-5570-00 070-5570-00 - 2012-2014 Outlaw Diesel Frame
$1399.99
2 028-6020-00 028-6020-00 - Rear Actuator Bar Assy (See Models Used On For Detail)
$106.48
4 017-7008-00 017-7008-00 - 1" Pillow Block Bearing (See Models Used On For Details)
$21.29
5 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
6 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
7 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
8 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
9 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
10 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
11 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
12 028-6055-00 028-6055-00 - Linkage Bar Suspension Frame (See Models Used On For Detail)
$28.39
13 035-7033-00 035-7033-00 - Actuator
$408.75
14 018-5049-00 018-5049-00 - 1/2-13 X 2 Hex Bolts Zinc
$2.99
15 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
16 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
17 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
18 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
19 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
20 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
21 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
22 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
23 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
24 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
25 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
26 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
27 079-3200-00 079-3200-00 - Outlaw Diesel Floor Panel
$64.19
28 081-2008-00 081-2008-00 - Foot Assist Floor Mat (See Models Used On For Details)
$66.76
29 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
30 018-8064-00 018-8064-00 - 1/4-20 X 5/8 BS C/S 18-8 SS
$2.99
31 064-2006-00 064-2006-00 - Floorboard Cable
$15.55
32 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
33 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
34 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
35 026-0013-00 026-0013-00 - 2010-2018 Outlaw & 2012-2018 Compact Diesel Deck Lift Pedal
$21.28
36 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
37 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
38 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
39 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
40 029-7037-00 029-7037-00 - 14" Bumper
$42.79
41 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
42 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
44 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
