2013 Diesels - Frame (Diesel)

2013 Diesels - Frame (Diesel)

The 2013 Diesels Frame (Diesel) provides the solid structure your mower needs to endure tough tasks. To maintain your mower’s frame, BadBoyMowerParts.com offers a range of Bad Boy Mower Parts designed for the 2013 Diesels Frame (Diesel) model. Our Bad Boy Mower Part diagrams make finding the right components simple, from frame bolts to mounting brackets. Whether you’re replacing worn-out parts or doing upgrades, our selection of Bad Boy Lawn Mower Parts guarantees high-quality replacements that fit perfectly. You can conveniently shop for Bad Boy Parts Online to ensure you get the right parts every time. To make it even easier to shop, we offer Free Shipping On Orders Over $100. Keep your 2013 Diesels frame strong and reliable with our genuine parts. Visit us today to find everything you need for your diesel-powered mower.

Bad Boy Mower Parts Lookup

2013 Diesels - Frame (Diesel)
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 070-5550-00 070-5550-00 - 2012-2020 Diesel 4 cyl 72 inch Frame
$1399.99
2 017-7008-00 017-7008-00 - 1" Pillow Block Bearing (See Models Used On For Details)
$21.29
3 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
4 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
5 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
6 028-7920-00 028-7920-00 - Actuator Bar (See Models Used On For Detail)
$116.99
7 031-7000-00 031-7000-00 - Height Indicator Tab and Collar (See Models Used On For Details)
$11.29
8 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
9 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
10 028-5203-00 028-5203-00 - Height Indicator (See Models Used On For Detail)
$28.39
11 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
12 039-2008-00 039-2008-00 - Deck Stop Bracket 2008
$11.34
13 035-7033-00 035-7033-00 - Actuator
$408.75
14 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
15 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
16 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
17 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
18 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
19 018-5049-00 018-5049-00 - 1/2-13 X 2 Hex Bolts Zinc
$2.99
20 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
21 077-5300-00 077-5300-00 - Deck Stop Switch
$9.89
22 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
23 013-2000-00 013-2000-00 - 10-24 Wing Nut
$2.99
24 079-6000-00 079-6000-00 - 2007-2020 Floor Panel (See Models Used On For Details)
$145.95
25 081-2007-00 081-2007-00 - Floor Mat - Diesel Models (See Models Used On For Details)
$66.76
26 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
27 018-8064-00 018-8064-00 - 1/4-20 X 5/8 BS C/S 18-8 SS
$2.99
28 064-2006-00 064-2006-00 - Floorboard Cable
$15.55
29 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
30 013-8039-00 013-8039-00 - 1/4-20 Hex Nut
$2.99
31 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
32 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
33 029-7037-00 029-7037-00 - 14" Bumper
$42.79
34 028-1000-00 028-1000-00 - Diesel Weight Bar Bracket (See Models Used On For Details)
$14.97
35 018-2005-00 018-2005-00 - 3/8-16 X 4-1/4 Hex Bolt
$2.99
36 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
37 088-2000-00 088-2000-00 - 58 lb Diesel Weight
$229.99
38 070-5520-00 070-5520-00 - 2007-2020 Diesel 4cyl Frame Suspension
$2099.99
