2012 Stand-On - Frame & Idler Assembly

2012 Stand-On - Frame & Idler Assembly

The Frame & Idler Assembly is an essential part of your 2012 Stand-On mower, providing the structural support and tension necessary for the proper functioning of the mower's drive system. If your frame or idler assembly is worn out or damaged, it can affect the mower’s performance. BadBoyMowerParts.com carries a wide variety of Bad Boy Mower Parts, including high-quality Bad Boy Lawn Mower Parts designed specifically for the 2012 Stand-On. Our extensive collection includes replacement frames, idlers, and related components to restore your mower to its optimal condition. With the help of our Bad Boy Mower Part diagrams, you can easily find the parts you need and make repairs with confidence. Shopping Bad Boy Parts Online is fast, secure, and convenient. Plus, enjoy Free Shipping On Orders Over $100, so you can save on shipping while getting your mower back to top form. Trust BadBoyMowerParts.com for all your frame and idler assembly needs.

Bad Boy Mower Parts Lookup

2012 Stand-On - Frame & Idler Assembly
  Position Number SKU Product Title Price
1 070-5200-00 070-5200-00 - 2012-2014 Stand-On Frame 54" Decks
$1299.00
2 039-5949-00 039-5949-00 - Stand On Pump Idler Bracket
$37.47
3 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
4 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
5 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
6 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
7 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
8 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
9 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
10 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
11 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
12 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
13 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
14 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
15 035-7033-00 035-7033-00 - Actuator
$408.75
16 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
18 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
19 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
21 201-1100-00 201-1100-00 - Stand Frame Support Stand On Model
$53.49
22 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
23 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
24 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
25 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
26 026-5040-00 026-5040-00 - Stand Plate for Stand On
$26.74
27 034-8045-00 034-8045-00 - Seat Spring
$20.49
28 014-8047-00 014-8047-00 - Rubber Cap Cover
$2.99
29 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
30 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
31 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
32 018-2006-00 018-2006-00 - 5/16-18 X 1-1/4 Hex Bolt
$2.99
33 034-1000-00 034-1000-00 - Spring Cushion (See Models Used On For Detail)
$28.39
34 026-5020-00 026-5020-00 - Ht Indicator Plate Stand On Bolt on
$10.99
35 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
36 018-2071-00 018-2071-00 - 3/8 x 2 1/2 Hex Tap Bolt - Ful l Thread - ACS
$2.99
37 040-4075-00 040-4075-00 - Pin and Lanyard for Stand-On
$12.48
39 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
40 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
41 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
42 030-3050-00 030-3050-00 - 10 X 1/2 Pan Phil a T/S Zinc
$2.99
43 029-4010-00 029-4010-00 - Button Bumper
$2.99
44 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
45 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
46 070-5210-00 070-5210-00 - 2012-2014 Stand-On Frame 48" Decks
$1299.99
