2012 CZT - Front Fork Assembly

2012 CZT - Front Fork Assembly

Introducing the 2012 CZT Front Fork Assembly, a component designed to provide excellent steering stability and accurate wheel alignment for your mower. This assembly is made from durable materials and manufactured with advanced techniques to ensure long service life and minimal vibration. Its design enhances maneuverability and contributes to a smoother ride in both residential and commercial applications. The assembly comes with clear installation instructions and maintenance guidelines to ensure a secure fit. Integrating with the CZT’s structure, the front fork assembly improves handling and overall efficiency. For detailed schematics, verified components, and expert support, please consult Bad Boy Mower Part diagrams, Bad Boy Mower Parts, Bad Boy Lawn Mower Parts, Bad Boy Parts Online and Free Shipping On Orders Over $100 available on our website. Visit BadBoyMowerParts.com for guidance and advice. Upgrade your mower with this front fork assembly to achieve excellent control every time. Enjoy performance today. Experience enhanced control and efficiency on every mow right now.

Bad Boy Mower Parts Lookup

2012 CZT - Front Fork Assembly
  Position Number SKU Product Title Price
1 023-7913-00 023-7913-00 - Front Fork-Non Suspension
$139.99
2 013-7004-00 013-7004-00 - 1-14 Hex Castle Nut Plain (Slotted Nut)
$8.35
3 012-7003-00 012-7003-00 - Bearing Seal - Front Caster (See Models Used On For Details)
$10.21
4 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
5 018-7010-00 018-7010-00 - 1/2-13 X 9" Hex Bolts Zinc
$5.82
6 014-7005-00 014-7005-00 - Dust Cover - Yellow Zinc
$9.34
7 020-7022-00 020-7022-00 - 1/8 X 2-1/4 Cotter Pins Zinc
$2.99
8A 011-7002-00 011-7002-00 - Race (44610) Front Caster (See Models Used On For Details)
$4.39
8B 010-7003-98 010-7003-98 - Front Caster Bearing, Race, and seal kit (See Models Used On For Details)
$30.99
8 010-7001-00 010-7001-00 - Tapered Roller Bearing - Caster- Race not included (See Models Used On For Details)
$6.26
9 022-2006-00 022-2006-00 - 13 x 6.50 - 6 Orange Tire and Wheel Assembly
$119.99
10 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
11 022-7009-00 022-7009-00 - 1 3/8" Small Bore Bearing-Hoosier
$13.36
