2010 Compact Diesel - Front Wheel Assembly

2010 Compact Diesel - Front Wheel Assembly

The 2010 Compact Diesel Front Wheel Assembly is vital for maintaining maneuverability, stability, and traction across various mowing conditions. At BadBoyMowerParts.com, we provide premium Bad Boy Mower Parts, including caster wheels, axle shafts, bearings, and brackets for durable performance. Our Bad Boy Lawn Mower Parts inventory ensures factory-quality replacements designed for reliability. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct front wheel assembly components for easy installation. Routine maintenance prevents premature wear, enhances mobility, and extends the lifespan of your mower’s front-end system. We also offer Bad Boy Parts Online, making it easy to order replacement wheel assembly components whenever needed. Plus, with Free Shipping On Orders Over $100, maintaining your 2010 Compact Diesel Front Wheel Assembly is now more affordable. Order today to ensure smooth movement, improved steering control, and long-lasting mower performance.

Bad Boy Mower Parts Lookup

2010 Compact Diesel - Front Wheel Assembly
  Position Number SKU Product Title Price
1 022-3060-00 022-3060-00 - 13 x 6.50 - 6 LARGE BORE, Orange Front Assembly
$122.99
2 032-9000-00 032-9000-00 - Isolator - Green Dot
$70.97
3A 010-7003-98 010-7003-98 - Front Caster Bearing, Race, and seal kit (See Models Used On For Details)
$30.99
3 010-7001-00 010-7001-00 - Tapered Roller Bearing - Caster- Race not included (See Models Used On For Details)
$6.26
4 022-7010-00 022-7010-00 - 1 3/4" Bearing - Large Bore Front Wheel
$20.32
5 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
6 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
7 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
8 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
9 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
10 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
11 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
12 018-3002-00 018-3002-00 - 1/2 x 10 Bolt
$8.02
13 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
14 011-7002-00 011-7002-00 - Race (44610) Front Caster (See Models Used On For Details)
$4.39
15 023-0013-00 023-0013-00 - Suspension Fork - Bottom Right
$31.58
16 023-0012-00 023-0012-00 - Suspension Fork - Bottom Left
$31.58
17 037-0010-00 037-0010-00 - Front Suspension Fork Spindle Shaft - Black
$42.58
18 023-7915-98 023-7915-98 - Suspension Fork Assembly
$350.99
19 013-6016-00 013-6016-00 - 1 Fine Thread Nut
$4.39
20 019-3000-00 019-3000-00 - 1" Lock Washer
$3.29
21 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
22 020-3000-00 020-3000-00 - 3/32 X 1 1/2 Cotter Pins Zinc
$2.99
23 014-7005-00 014-7005-00 - Dust Cover - Yellow Zinc
$9.34
24 012-7003-00 012-7003-00 - Bearing Seal - Front Caster (See Models Used On For Details)
$10.21
