2011 Pup and Lightning - Front Wheel w/ Suspension

2011 Pup and Lightning - Front Wheel w/ Suspension

For an added level of comfort and control, the 2011 Pup and Lightning Front Wheel w/ Suspension is a key feature that provides smoother handling across various terrains. If you're looking to replace or upgrade this component, BadBoyMowerParts.com offers the highest quality Bad Boy Mower Parts for your 2011 Pup and Lightning models. Our Bad Boy Mower Part diagrams make finding the right part a breeze, ensuring you get exactly what you need. The front wheel with suspension is designed for durability and ease of movement, which will keep your mower performing at its best. We offer a wide selection of Bad Boy Lawn Mower Parts, all built to last and perform. When you shop Bad Boy Parts Online, you can take advantage of Free Shipping On Orders Over $100. Ensure your mower is ready for any terrain with the front wheel assembly and suspension from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2011 Pup and Lightning - Front Wheel w/ Suspension
  Position Number SKU Product Title Price
1 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
2 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
3 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
4 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
5 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
6 032-9002-00 032-9002-00 - Isolator - Red Dot
$70.97
7A 011-7002-00 011-7002-00 - Race (44610) Front Caster (See Models Used On For Details)
$4.39
7 012-7003-00 012-7003-00 - Bearing Seal - Front Caster (See Models Used On For Details)
$10.21
8 010-7001-00 010-7001-00 - Tapered Roller Bearing - Caster- Race not included (See Models Used On For Details)
$6.26
9 022-1050-00 022-1050-00 - 13 x 6.50-6 No-Flat Tire and Wheel Assembly
$177.99
10 022-7010-00 022-7010-00 - 1 3/4" Bearing - Large Bore Front Wheel
$20.32
11 018-3002-00 018-3002-00 - 1/2 x 10 Bolt
$8.02
12 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
13 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
14 019-3000-00 019-3000-00 - 1" Lock Washer
$3.29
15 037-0010-00 037-0010-00 - Front Suspension Fork Spindle Shaft - Black
$42.58
16 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
17 014-7005-00 014-7005-00 - Dust Cover - Yellow Zinc
$9.34
