2014 Outlaw & Outlaw Extreme - Deck Lift Assembly

2014 Outlaw & Outlaw Extreme - Deck Lift Assembly

The 2014 Outlaw & Outlaw Extreme Deck Lift Assembly is a vital part of your mower, enabling smooth and precise control over your mowing height. At BadBoyMowerParts.com, we offer a full selection of Bad Boy Mower Parts that are compatible with the deck lift system. Our Bad Boy Mower Part Diagrams provide clear, detailed views of each component, ensuring that you can find the exact parts you need. With Bad Boy Lawn Mower Parts, you’ll receive durable, reliable components designed to keep your 2014 Outlaw & Outlaw Extreme operating smoothly. You can easily shop for all the necessary parts Bad Boy Parts Online, with the added bonus of Free Shipping On Orders Over $100. This means you get the parts you need at a great price and have them delivered right to your doorstep with no extra shipping fees.

Bad Boy Mower Parts Lookup

2014 Outlaw & Outlaw Extreme - Deck Lift Assembly
  Position Number SKU Product Title Price
1 070-5350-00 070-5350-00 - 2012-2014 Outlaw/Outlaw Extreme Frame
$1299.99
2 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
3 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
4 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
5 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
6 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
7 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
8 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
9 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
10 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
11 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
12 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
13 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
14 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
15 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
16 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
17 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
18 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
19 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
20 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
21 028-6010-00 028-6010-00 - Front Actuator Bar Assy (See Models Used On For Detail)
$142.99
22 028-6050-00 028-6050-00 - Outlaw Deck Linkage Rod
$28.39
23 017-7008-00 017-7008-00 - 1" Pillow Block Bearing (See Models Used On For Details)
$21.29
24 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
25 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
27 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
29 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
30 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
31 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper (See Models Used On For Details)
$4.83
32 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
33 026-2110-00 026-2110-00 - Outlaw Rear Plate
$199.99
34 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
35 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
36 072-8074-00 072-8074-00 - 5/8" Wire Clamp - Outlaw & Rebel
$4.81
37 051-9000-00 051-9000-00 - 5/8 Braided Hose Priced per Foot
$4.81
38 066-5050-00 066-5050-00 - Hydraulic Tank Cap (See Models Used On For Details)
$15.60
39 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
40 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
41 067-8085-00 067-8085-00 - Expansion Tank for Outlaw (See Models Used On For Details)
$31.22
42 029-7037-00 029-7037-00 - 14" Bumper
$42.79
43 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
44 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
45 026-0013-00 026-0013-00 - 2010-2018 Outlaw & 2012-2018 Compact Diesel Deck Lift Pedal
$21.28
46 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
47 201-1050-00 201-1050-00 - Spoiler Support Right
$35.48
48 201-1051-00 201-1051-00 - Spoiler Support Left
$35.48
49 026-1040-00 026-1040-00 - Outlaw Spoiler Plate
$106.99
50 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
51 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
52 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Deck Damper
$62.40
53 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
54 028-6020-00 028-6020-00 - Rear Actuator Bar Assy (See Models Used On For Detail)
$106.48
