2013 Diesels - Pump Plate Assembly

2013 Diesels - Pump Plate Assembly

The 2013 Diesels Pump Plate Assembly is essential for the proper functioning of your mower’s hydraulic system, transferring fluid to vital parts. At BadBoyMowerParts.com, we provide an extensive range of Bad Boy Mower Parts for the 2013 Diesels Pump Plate Assembly. Whether you’re replacing the entire assembly or just a specific component, our Bad Boy Mower Part diagrams guide you in selecting the correct parts for a perfect fit. We offer high-quality Bad Boy Lawn Mower Parts that are designed for durability and performance. Ordering Bad Boy Parts Online is quick and straightforward, and with Free Shipping On Orders Over $100, you can save while maintaining your mower’s efficiency. Browse our selection today and ensure your 2013 Diesels hydraulic system continues to function smoothly with the right pump plate assembly.

Bad Boy Mower Parts Lookup

2013 Diesels - Pump Plate Assembly
  Position Number SKU Product Title Price
1 026-8030-00 026-8030-00 - Pump Plate Diesel (See Models Used On For Details)
$109.99
2 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
3 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
4 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
5 039-5950-00 039-5950-00 - Pump Idler Bracket 60 Diesel
$32.65
6 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
7 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
8 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
9 033-4050-00 033-4050-00 - 5" V Idler 35hp Diesel
$37.79
10 025-7020-00 025-7020-00 - 5/8 Set Collar w/One Set Screw
$4.37
11 033-5011-00 033-5011-00 - Cast Pump Pulley - 17mm AOS/Diesel Models
$35.48
12 070-5040-00 070-5040-00 - Diesel/Vanguard PTO Clutch
$399.00
13 032-4000-00 032-4000-00 - Rubber for Rear Diesel Motor Mount
$76.53
15 032-4051-00 032-4051-00 - Snubbing Washer for Rubber Compression Mount
$17.02
16 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
17 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
18 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
19 019-8053-00 019-8053-00 - 7/16 Lockwasher zinc
$2.99
20 018-5401-00 018-5401-00 - 7/16 x 2 3/4 Fine Thread Bolt
$2.99
21 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
22 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
23 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
25 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
26 057-5910-10 057-5910-10 - 2010-2020 Diesel PTO Engager Holder
$22.71
27 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
28 051-8076-00 051-8076-00 - 3/8 Fuel Line-Priced per Foot
$6.59
29 050-5500-00 050-5500-00 - PR Pump w/Fan 16cc Left Compact Diesel (See Models Used On For Details)
$599.99
30 031-5923-00 031-5923-00 - Pump Arm
$30.07
31 050-5501-00 050-5501-00 - PR Pump w/Fan and Cover Right Compact Diesel PR2HCC-GY1G
$599.99
32 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
33 018-5005-00 018-5005-00 - 1/4-20 X 1-1/2 Hex Bolt
$2.99
34 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
35 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
36 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
37 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
38 024-2060-00 024-2060-00 - 6801-LL-8-8 Fitting - Diesels
$26.53
39 024-5002-00 024-5002-00 - 90 Degree Fitting, 1/2 x 3/4, 986741
$17.63
40 024-5206-00 024-5206-00 - 90 Degree Fitting, 3/8 x 9/16, 4601-6-6
$12.42
41 014-5500-00 014-5500-00 - Fan Guard 7"
$39.03
42 015-9999-00 015-9999-00 - Hydro Fan - Fits Hydraulic Pumps
$28.88
43 042-5012-00 042-5012-00 - 5MM X 1.25 Square Key (obsolete)
use part #042-5013-00
$2.99
44 041-5048-00 041-5048-00 - Pump Belt (See Models Used On For Details)
$60.98
45 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
46 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
47 018-7055-00 018-7055-00 - 3/8-16 x 5 Hex Bolt -
$2.99
48 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
49 063-2011-00 063-2011-00 - CAT Fuel Filter - Big
$29.95
50 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
53 015-0007-00 015-0007-00 - Caterpillar Fuel Bowl Kit
$150.99
54 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
55 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
57 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
58 051-8075-00 051-8075-00 - 5/16 Fuel Line Hose Priced per Foot
$7.69
59 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
60 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
61 039-5946-98 039-5946-98 - Pump Idler Bracket Assy Diesel
$56.77
62 050-5308-00 050-5308-00 - Left Pump 16cc - AOS/Diesel (See Models Used On For Details)
$899.99
63 050-5407-00 050-5407-00 - Right Pump 16cc - AOS/Diesel (See Models Used On For Details)
$899.99
64 041-8411-00 041-8411-00 - Pump Belt (See Models Used On For Detail)
$64.19
65 039-5945-98 039-5945-98 - Pump Idler 72" (35HP) Assy (See Models Used On For Details)
$56.77
67 018-6016-00 018-6016-00 - 5/8 x 5 1/2 Bolt
$2.99
