2012 Outlaw & Outlaw Extreme - Seat Assembly

2012 Outlaw & Outlaw Extreme - Seat Assembly

The seat assembly on your 2012 Outlaw & Outlaw Extreme mower is important for comfort and support during long mowing sessions. If your seat is worn out or damaged, BadBoyMowerParts.com offers a variety of Bad Boy Mower Parts designed to restore your mower to its original comfort level. Our Bad Boy Mower Part diagrams help you identify the specific seat and related components you need. We carry a wide range of Bad Boy Lawn Mower Parts that are built for durability and comfort, ensuring you can mow for hours without discomfort. Shopping Bad Boy Parts Online is easy with our user-friendly website, and we ensure fast processing and secure delivery. Plus, with Free Shipping On Orders Over $100, you’ll save on delivery costs while ensuring you get the best parts for your mower. Whether you’re replacing an old seat or upgrading to a new one, BadBoyMowerParts.com is your go-to source for high-quality seat assemblies for your 2012 Outlaw & Outlaw Extreme.

Bad Boy Mower Parts Lookup

2012 Outlaw & Outlaw Extreme - Seat Assembly
  Position Number SKU Product Title Price
1 080-5000-00 080-5000-00 - Outlaw Seat Bracket 2012 Assembly
$399.99
2 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
3 018-8059-00 018-8059-00 - 5/16-18x1-3/4 Hex Bolt
$2.99
4 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
5 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
7 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
8 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
9 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
10 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
11 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
12 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
13 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
14 018-1010-00 018-1010-00 - 3/8-16 x 3-1/2 Hex Bolt
$2.99
16 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
17 064-8081-00 064-8081-00 - Seat Cable
$15.60
18 034-8045-00 034-8045-00 - Seat Spring
$20.49
19 014-8047-00 014-8047-00 - Rubber Cap Cover
$2.99
21 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
22 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
23 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
25 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
26 018-4700-00 018-4700-00 - 3/8-16 X 3 Hex Bolts Zinc
$2.99
27 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
28 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
30 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
31 071-5000-00 071-5000-00 - 2010-2014 Outlaw Seat Use without ROPS (obsolete)
use part #071-5060-00
$699.99
32 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
33 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
34 014-2100-00 014-2100-00 - Outlaw Cooler Cover
$21.39
35 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F Thread Cutting Screw
$2.99
36 018-0011-00 018-0011-00 - 1/4-20 x 2 Hex Bolt
$2.99
39 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
40 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
42 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
