2012 Outlaw XP - Seat Assembly

2012 Outlaw XP - Seat Assembly

The 2012 Outlaw XP Seat Assembly is a crucial part of your mower, ensuring comfort and support during long mowing sessions. BadBoyMowerParts.com offers a variety of Bad Boy Mower Parts to help you maintain or replace your seat assembly. Whether you need a complete seat replacement or individual parts like the frame, cushion, or mounting hardware, we have you covered. Our Bad Boy Lawn Mower Parts are designed to fit the 2012 Outlaw XP perfectly, ensuring a secure and comfortable seating experience. Our website features detailed Bad Boy Mower Part diagrams to help you identify the right parts for your mower, making your repairs straightforward. When you shop Bad Boy Parts Online, you'll find an easy-to-navigate website with a wide selection of parts. Plus, take advantage of Free Shipping On Orders Over $100, saving you money while ensuring your mower stays in top condition. Visit BadBoyMowerParts.com today for all your seat assembly needs.

Bad Boy Mower Parts Lookup

2012 Outlaw XP - Seat Assembly
  Position Number SKU Product Title Price
1 080-5000-00 080-5000-00 - Outlaw Seat Bracket 2012 Assembly
$399.99
2 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
3 018-8059-00 018-8059-00 - 5/16-18x1-3/4 Hex Bolt
$2.99
4 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
5 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
7 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
8 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
9 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
10 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
11 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
12 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
13 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
14 018-1010-00 018-1010-00 - 3/8-16 x 3-1/2 Hex Bolt
$2.99
16 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
17 064-8081-00 064-8081-00 - Seat Cable
$15.60
18 034-8045-00 034-8045-00 - Seat Spring
$20.49
19 014-8047-00 014-8047-00 - Rubber Cap Cover
$2.99
21 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
22 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
23 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
25 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
26 018-4700-00 018-4700-00 - 3/8-16 X 3 Hex Bolts Zinc
$2.99
27 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
28 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
30 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
31 071-5000-00 071-5000-00 - 2010-2014 Outlaw Seat Use without ROPS (obsolete)
use part #071-5060-00
$699.99
32 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
33 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
34 014-2100-00 014-2100-00 - Outlaw Cooler Cover
$21.39
35 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F Thread Cutting Screw
$2.99
36 018-0011-00 018-0011-00 - 1/4-20 x 2 Hex Bolt
$2.99
37 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5)
$2.99
39 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
40 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
42 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
44 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
45 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
46 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
47 024-5342-00 024-5342-00 - Fitting 1/2 x 3/8 Barb 206-108
$7.95
48 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
49 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
50 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
51 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
52 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
53 051-8064-00 051-8064-00 - 1/2 Clear Braided Hose PRICED/ FOOT
$2.99
54 072-8066-00 072-8066-00 - 1/2" Hose Clamp
$2.99
55 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
56 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
