2015 Compact Diesel - Seat Frame

2015 Compact Diesel - Seat Frame

The 2015 Compact Diesel Seat Frame ensures stability and support while you operate your mower, making comfort and durability a priority. If your seat frame is damaged, BadBoyMowerParts.com has the replacement Bad Boy Mower Parts you need. Our Bad Boy Mower Part Diagrams help identify the exact seat frame for your mower, ensuring a perfect fit. Properly maintaining Bad Boy Lawn Mower Parts, including seating components, enhances comfort and safety. Whether you need a seat frame or mounting hardware, we have it in our Bad Boy Parts Online inventory. Order today and enjoy Free Shipping On Orders Over $100, making your mower repairs more affordable. Shop at BadBoyMowerParts.com for durable seat frame replacements that provide stability and comfort for long mowing sessions.

Bad Boy Mower Parts Lookup

2015 Compact Diesel - Seat Frame
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
2 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
3 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
4 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
5 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
6 018-8059-00 018-8059-00 - 5/16-18x1-3/4 Hex Bolt
$2.99
7 080-7000-00 080-7000-00 - 2007 Diesel Seat Frame
$399.99
9 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
10 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
11 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
12 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
13 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
14 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
16 066-8050-00 066-8050-00 - Hydraulic Tank Cap w/Dipstick (See Models Used On For Details)
$31.22
17 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
18 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
19 051-8064-00 051-8064-00 - 1/2 Clear Braided Hose PRICED/ FOOT
$2.99
21 055-8018-75 055-8018-75 - Diesel Thottle Cable ONLY
$32.09
22 034-1000-00 034-1000-00 - Spring Cushion (See Models Used On For Detail)
$28.39
23 077-6000-00 077-6000-00 - Momentary Start Switch Preheat Button for Diesel
$21.39
24 014-6000-00 014-6000-00 - Start Switch Boot - Diesel
$6.59
25 021-8059-00 021-8059-00 - Heat Warning Piezo Buzzer
$36.37
26 015-0015-00 015-0015-00 - Auto Shut Down for Cat Diesels
$699.99
27 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
28 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
29 013-8039-00 013-8039-00 - 1/4-20 Hex Nut
$2.99
30 072-8066-00 072-8066-00 - 1/2" Hose Clamp
$2.99
31 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
32 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
33 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
34 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
35 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
36 064-4001-00 064-4001-00 - Black Battery Cable (See Models Used On For Details)
$22.31
37 064-4000-00 064-4000-00 - Red Battery Cable (See Models Used On For Details)
$23.53
38 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
39 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
40 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
41 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
42 071-4050-00 071-4050-00 - Grammer Suspension Seat Use w/o ROPS - Obsolete - USE PART #071-4050-17 (obsolete)
use part #071-4050-17
$759.99
45 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
47 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
48 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5)
$2.99
49 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
50 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
51 014-2009-00 014-2009-00 - Cooler Cover (See Models Used On For Details)
$117.94
53 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
54 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
55 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
56 018-4007-00 018-4007-00 - 1/4-20 X 1 Hex Bolts Zinc
$2.99
57 025-2000-00 025-2000-00 -.380x.735x.470 Nylon Spacer
$2.99
