2010 CZT - Seat & Tanks

2010 CZT - Seat & Tanks

The 2010 CZT Seat & Tanks provide operator comfort and efficient fuel storage, ensuring smooth and uninterrupted mowing. At BadBoyMowerParts.com, we supply high-quality Bad Boy Mower Parts, including seats, fuel tanks, mounting brackets, and replacement cushions for durability. Our Bad Boy Lawn Mower Parts inventory guarantees factory-grade replacements built for operator comfort and long-term use. Using our Bad Boy Mower Part diagrams, you can quickly find and order the correct seat and tank components for seamless installation. Routine maintenance prevents leaks, enhances comfort, and extends fuel system lifespan. We also stock Bad Boy Parts Online, making it easy to order necessary seat and tank components whenever needed. Plus, with Free Shipping On Orders Over $100, maintaining your 2010 CZT Seat & Tanks is now more budget-friendly. Order today to ensure a comfortable ride, secure fuel storage, and optimized mower performance.

Bad Boy Mower Parts Lookup

2010 CZT - Seat & Tanks
  Position Number SKU Product Title Price
1 014-3410-00 014-3410-00 - 2010-2012 CZT/ZT Cooler Cover w/o Choke Hole
$92.29
2 026-0052-00 026-0052-00 -Pump Cover Plate (See Models Used On For Details)
$83.77
3 026-0053-00 026-0053-00 -Rear Plate (See Models Used On For Details)
$229.99
4 026-1010-00 026-1010-00 - ZT Seat Plate 2010 (See Models Used On For Details)
$99.32
5A 077-8076-00 077-8076-00 - 3-Position Ignition Switch (key not included)
$21.39
5 042-9000-00 042-9000-00 - Ignition Key
$4.06
6 056-8058-00 056-8058-00 - PTO Engager-Switch for Blades
$34.29
7 066-8076-00 066-8076-00 - Non-Tethered Fuel Kelch Cap - 3.5 Neck
$32.05
8A 067-7000-50 067-7000-50 - Right Fuel Tank (See Models Used On below for detail)
$329.99
8 067-7001-50 067-7001-50 - Left Fuel Tank 2008-2012 CZT/ZT
$360.99
9 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
10A 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
10 071-8061-00 071-8061-00 - Seat Switch (See Models Used On For Detail)
$19.14
11A 071-8090-00 071-8090-00 - Black ZT Seat - No Armrests OBSOLETE use 071-1000-00 (obsolete)
use part #071-1000-00
$429.99
11B 071-3000-00 071-3000-00 - Milsco Suspension Seat-AOS/Lig OBSOLETE use 071-4050-17 (obsolete)
use part #071-4050-17
$759.99
11 071-2010-00 071-2010-00 - Wise Seat - ZT - WM1976 OBSOLETE use 071-2040-00 (obsolete)
use part #071-2040-17
$559.99
12 078-8077-00 078-8077-00 - Joystick - Deck Lift
$42.79
13 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
15 067-4025-00 067-4025-00 - Fuel Gauge and Grommet (See Models Used On For Details)
$54.56
16A 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
16 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
18 081-2010-00 081-2010-00 - 2010-2015 CZT & 2010-2013 ZT Floor Mat
$28.45
19 079-3410-00 079-3410-00 - 2010-2012 ZT Floor Panel
$106.99
20 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
21 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
22 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
23 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
