2010 ZT - Seat & Tanks

2010 ZT - Seat & Tanks

The 2010 ZT Seat & Tanks provide operator comfort and secure fuel storage for extended mowing sessions. At BadBoyMowerParts.com, we offer premium Bad Boy Mower Parts, including seats, fuel tanks, mounting brackets, and cushion supports for durability and convenience. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements designed for long-term performance. Using our Bad Boy Mower Part diagrams, you can quickly identify and order the correct seat and tank components for easy installation. Routine maintenance prevents fuel leaks, improves seat stability, and extends the lifespan of your mower’s seating and fuel system. With access to Bad Boy Parts Online, ordering essential seat and tank components is simple and efficient. Plus, with Free Shipping On Orders Over $100, maintaining your 2010 ZT Seat & Tanks is now more budget-friendly. Order today to enhance operator comfort, secure fuel storage, and maximize mowing efficiency.

Bad Boy Mower Parts Lookup

2010 ZT - Seat & Tanks
  Position Number SKU Product Title Price
1 014-3410-00 014-3410-00 - 2010-2012 CZT/ZT Cooler Cover w/o Choke Hole
$92.29
2 026-0052-00 026-0052-00 -Pump Cover Plate (See Models Used On For Details)
$83.77
3 026-0053-00 026-0053-00 -Rear Plate (See Models Used On For Details)
$229.99
4 026-1010-00 026-1010-00 - ZT Seat Plate 2010 (See Models Used On For Details)
$99.32
5A 077-8076-00 077-8076-00 - 3-Position Ignition Switch (key not included)
$21.39
5 042-9000-00 042-9000-00 - Ignition Key
$4.06
6 056-8058-00 056-8058-00 - PTO Engager-Switch for Blades
$34.29
7 066-8076-00 066-8076-00 - Non-Tethered Fuel Kelch Cap - 3.5 Neck
$32.05
8A 067-7000-50 067-7000-50 - Right Fuel Tank (See Models Used On below for detail)
$329.99
8 067-7001-50 067-7001-50 - Left Fuel Tank 2008-2012 CZT/ZT
$360.99
9 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
10A 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
10 071-8061-00 071-8061-00 - Seat Switch (See Models Used On For Detail)
$19.14
11A 071-8090-00 071-8090-00 - Black ZT Seat - No Armrests OBSOLETE use 071-1000-00 (obsolete)
use part #071-1000-00
$429.99
11B 071-3000-00 071-3000-00 - Milsco Suspension Seat-AOS/Lig OBSOLETE use 071-4050-17 (obsolete)
use part #071-4050-17
$759.99
11 071-2010-00 071-2010-00 - Wise Seat - ZT - WM1976 OBSOLETE use 071-2040-00 (obsolete)
use part #071-2040-17
$559.99
12 078-8077-00 078-8077-00 - Joystick - Deck Lift
$42.79
13 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
15 067-4025-00 067-4025-00 - Fuel Gauge and Grommet (See Models Used On For Details)
$54.56
16A 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
16 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
18 081-2010-00 081-2010-00 - 2010-2015 CZT & 2010-2013 ZT Floor Mat
$28.45
19 079-3410-00 079-3410-00 - 2010-2012 ZT Floor Panel
$106.99
20 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
21 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
22 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
23 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
