2013 Diesels Suspension

Suspension

The Bad Boy Mower parts diagram for the 2013 Diesels Suspension is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2013 Diesels models. Find all of your Bad Boy mowers 2013 Diesels parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2013 Diesels Suspension. If you are not able to find the Bad Boy parts for your 2013 Diesels please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2013 Diesels Suspension
  Position Number SKU Product Title Price
1 018-2051-00 018-2051-00 - 5/8 x 10 Bolt Grade 8
$15.61
2 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknu t Zinc
$2.99
3 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
4 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
5 018-2030-00 018-2030-00 - 1/2 x 1 Bolt
$2.99
6 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
7 070-8000-00 070-8000-00 - 60 Suspension Kit Wheel Motor
$312.34
8 032-8999-00 032-8999-00 - Vibration Mount - Blue Dot Rear Mount for Diesel Models
$64.22
9A 072-1000-98 072-1000-98 - Isolator Clamp Assembly
$28.39
9 072-1000-00 072-1000-00 - Isolator Band Clamp
$7.28
10 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
11 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
12 020-7022-00 020-7022-00 - 1/8 X 2-1/4 Cotter Pins Zinc
$2.99
13 042-7041-00 042-7041-00 - Woodruff Key-Wheel Motor
$14.19
14 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
15 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 GR 5 Bolt Zinc
$2.99
16 015-4600-00 015-4600-00 - 18cc Parker Wheel Motor-Right AOS/Diesel
$640.93
17 013-7050-00 013-7050-00 - 1" Castle Nut for Wheel Motor (obsolete)
use part #013-7055-00
$15.61
19 092-1075-00 092-1075-00 - NO LONGER AVAILABLE. FOR RIGHT SIDE ORDER 092-1075-01, FOR LEFT SIDE ORDER 092-1075-02 No Longer Available
Obsolete.
20 025-0006-00 025-0006-00 - Ausco Brake Spacer
$4.37
21 024-0050-00 024-0050-00 - 45 Degree Fitting 31704-10-10
$31.17
22 092-1000-00 092-1000-00 - Right Brake Caliper 2012-2013
$85.17
23 039-2140-00 039-2140-00 - Ausco Caliper Mounting Bracket
$7.28
24 018-4700-00 018-4700-00 - 3/8-16 X 3 GR 5 Hex Bolts Zinc
$2.99
25 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
26 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut Z inc Orange Nylon
$2.99
28 015-4601-00 015-4601-00 - 18cc Parker Wheel Motor - Left AOS/Diesel
$640.93
29 092-1050-00 092-1050-00 - Left Brake Caliper 2012-2013
$85.17
55 051-2080-00 051-2080-00 - 26" Hydraulic Hose Assembly w/Adaptors
$156.17
56 022-7031-00 022-7031-00 - 26 x 12.00 - 12 Tire and Orang e Wheel Assembly
$458.99
57 022-7034-00 022-7034-00 - 12 x 10.5 Wheel - AOS Rear
$235.99
58 022-7032-00 022-7032-00 - 26 x 12.00 - 12 Tire (One Tire Only)
$331.99
59 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
63 070-8001-00 070-8001-00 - 72 Suspension Kit Wheel Motor
$283.95
64 018-2080-00 018-2080-00 - 1/2-13 X 1-1/4 Hex Bolt
$2.99
65 051-6085-00 051-6085-00 - 26 inch Hose Only
$40.53
