2012 Outlaw XP - Suspension Fork Assembly

2012 Outlaw XP - Suspension Fork Assembly

The 2012 Outlaw XP Suspension Fork Assembly is essential for maintaining a smooth ride while mowing uneven terrain. If you need to repair or replace this critical component, BadBoyMowerParts.com is your trusted source for Bad Boy Mower Parts. We carry a full range of Bad Boy Lawn Mower Parts, including suspension forks and related components designed for the 2012 Outlaw XP. Our Bad Boy Mower Part diagrams help you easily locate and identify the correct suspension fork assembly parts for your mower. Whether you're performing an upgrade or simply replacing worn components, our high-quality parts are built to last, ensuring optimal performance. Shopping Bad Boy Parts Online makes it easy to place your order, and our efficient processing ensures quick delivery. Plus, with Free Shipping On Orders Over $100, you can save on shipping costs while getting the best parts for your mower. Trust BadBoyMowerParts.com for all your suspension fork assembly needs.

Bad Boy Mower Parts Lookup

2012 Outlaw XP - Suspension Fork Assembly
  Position Number SKU Product Title Price
1 023-0020-00 023-0020-00 - 2012-2016 Outlaw XP, 2012-2020 Diesel Suspension Fork Top/Side Combo
$263.99
2 023-0012-00 023-0012-00 - Suspension Fork - Bottom Left
$31.58
3 023-0013-00 023-0013-00 - Suspension Fork - Bottom Right
$31.58
4 037-0010-00 037-0010-00 - Front Suspension Fork Spindle Shaft - Black
$42.58
5 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
6 018-2030-00 018-2030-00 - 1/2 x 1 Bolt
$2.99
7 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
8 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
9 032-9002-00 032-9002-00 - Isolator - Red Dot
$70.97
10 013-6016-00 013-6016-00 - 1 Fine Thread Nut
$4.39
11 019-3000-00 019-3000-00 - 1" Lock Washer
$3.29
12 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
13 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
14 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
15A 011-7002-00 011-7002-00 - Race (44610) Front Caster (See Models Used On For Details)
$4.39
15 010-7001-00 010-7001-00 - Tapered Roller Bearing - Caster- Race not included (See Models Used On For Details)
$6.26
16A 010-7003-98 010-7003-98 - Front Caster Bearing, Race, and seal kit (See Models Used On For Details)
$30.99
16 012-7003-00 012-7003-00 - Bearing Seal - Front Caster (See Models Used On For Details)
$10.21
17 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
18 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
19 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
20 018-3002-00 018-3002-00 - 1/2 x 10 Bolt
$8.02
21 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
22 014-7005-00 014-7005-00 - Dust Cover - Yellow Zinc
$9.34
23 022-3060-00 022-3060-00 - 13 x 6.50 - 6 LARGE BORE, Orange Front Assembly
$122.99
24 022-7010-00 022-7010-00 - 1 3/4" Bearing - Large Bore Front Wheel
$20.32
25 018-2080-00 018-2080-00 - 1/2-13 X 1-1/4 Hex Bolt
$2.99
26 023-7915-98 023-7915-98 - Suspension Fork Assembly
$350.99
