2013 MZ - Transaxle

2013 MZ - Transaxle

The 2013 MZ Transaxle is a critical part of your mower's drivetrain, and BadBoyMowerParts.com offers the high-quality parts necessary for maintenance or repair. We provide a wide range of components for the 2013 MZ transaxle system, from belts to gears and housings. Our Bad Boy Mower Part diagrams make it easy to locate the exact parts you need for your mower’s transmission system. We carry Bad Boy Mower Parts that are designed to keep your mower running at its best. Whether you're replacing the entire transaxle or individual components, you can trust us to provide durable, reliable parts. With Bad Boy Lawn Mower Parts available, you can be sure your mower will stay in top condition. Enjoy Free Shipping On Orders Over $100 when you shop with us, and browse Bad Boy Parts Online for all your mower’s transaxle needs.

Bad Boy Mower Parts Lookup

2013 MZ - Transaxle
  Position Number SKU Product Title Price
1 201-2020-00 201-2020-00 - MZ Transaxle Support (Lower)
$19.81
2 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
3 050-4030-00 050-4030-00 - EZT - Right - MZ Models ZC-APBB-3DKB-1FPX
$999.99
4 050-4031-00 050-4031-00 - EZT - Left Transaxle- MZ Models ZC-DPBB-3DKC-1FPX
$999.99
5 040-2025-00 040-2025-00 - Cotter Pin-Brake Bar on MZ
$2.99
6 039-1124-00 039-1124-00 - Brake Lock Bracket
$9.89
8 099-6046-00 099-6046-00 - Ball Joint - 3/8-24 (See Models Used On For Details)
$12.83
9 099-2009-00 099-2009-00 - Quick Release Ball Joint (See Models Used On For Details)
$9.89
11 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
12 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
13 034-3050-00 034-3050-00 - Spring-Brake Lock Bracket MZ
$2.99
14 028-0060-00 028-0060-00 - Brake Release Bar (See Models Used On For Detail)
$7.28
15 022-8026-00 022-8026-00 - Rear Wheel 48in MZ (One Rim Only)
$106.19
16 022-8025-00 022-8025-00 - 18x9.50-8 Rear Tire Only (One Tire Only)
$197.99
17 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
18 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
19 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
20 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
21 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
22 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
23 018-4701-00 018-4701-00 - 5/16-18 X 3 Hex Bolt Zinc
$2.99
24 018-1076-00 018-1076-00 - 1/4-20 x 2-1/2 Gr2 Hex C/S Zinc
$2.99
25 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
26 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
27 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
28 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
29 050-2074-00 050-2074-00 - Fan/Pulley Kit for 2012-2016 MZ/MZ Magnum
$65.26
30 022-8027-00 022-8027-00 - 18x8.50-8 Rear Tire Only 42 MZ (One Tire Only)
$136.99
31 022-8028-00 022-8028-00 - Rear Wheel 42in MZ (One Rim Only)
$85.27
32 022-8050-00 022-8050-00 - 18x9.50-8 Tire and Wheel Assembly (One Tire & Rim Assy)
$229.99
33 022-2050-00 022-2050-00 - 18x8.50-8 w/8" Tire & Wheel Assembly Fits 42" MZ
$202.99
34 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
