2011 Diesels - Wheel Motor

2011 Diesels - Wheel Motor

The 2011 Diesels Wheel Motor is crucial for powering the wheels, ensuring that your mower moves efficiently across various terrains. BadBoyMowerParts.com offers a wide range of Bad Boy Mower Parts, including the wheel motor for your 2011 Diesels. With the help of our Bad Boy Mower Part diagrams, you can easily find the exact motor for your mower model, making the replacement process straightforward. We provide only high-quality Bad Boy Lawn Mower Parts, ensuring that your wheel motor is durable and reliable. By shopping Bad Boy Parts Online, you can quickly find the part you need and have it delivered to your door with ease. Plus, enjoy Free Shipping On Orders Over $100, making it even more affordable to maintain your mower’s performance. Don’t let a worn-out wheel motor slow you down – replace it today and keep your mower running smoothly.

Bad Boy Mower Parts Lookup

2011 Diesels - Wheel Motor
  Position Number SKU Product Title Price
1 092-2075-00 092-2075-00 - 2011-2012 Diesel, 2011 Lightning/Pup Drum Brake Hub - HGB-DEXX-X5
$163.99
2 024-2050-00 024-2050-00 - 45 Degree Wheel Motor Fitting
$17.02
3 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread
$3.62
4 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
5 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
6 020-7022-00 020-7022-00 - 1/8 X 2-1/4 Cotter Pins Zinc
$2.99
7 042-7041-00 042-7041-00 - Woodruff Key-Wheel Motor
$14.19
8 092-6050-00 092-6050-00 - Obsolete - Must Buy 016-9999-98 (Left) or 016-9999-99 (Right) Disc Kit
$42.52
9 015-4600-00 015-4600-00 - 18cc Parker Wheel Motor-Right (See Models Used On for Detail)
$599.99
10 015-4601-00 015-4601-00 - 18cc Parker Wheel Motor
$599.99
11 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
12 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
13 022-7034-00 022-7034-00 - 12 x 10.5 Wheel - AOS/Diesel Rear
$219.99
14 022-7032-00 022-7032-00 - 26x12.00-12 Tire (One Tire Only)
$309.99
15 022-7031-00 022-7031-00 - 26x12.00-12 Orange Wheel and Tire Assembly
$428.99
16 031-0011-00 031-0011-00 - Discontinued - Use 016-9999-98 (obsolete)
use part #016-9999-98
$191.99
17 031-0012-00 031-0012-00 - Discontinued - Use 016-9999-99 (obsolete)
use part #016-9999-99
$191.99
18 051-6085-00 051-6085-00 - 26" Hydro Hose Only
$40.53
19 092-2000-00 092-2000-00 - Drum Brake - Left (See Models Used On For Details) (obsolete)
use part #016-9999-98
$191.99
20 092-2050-00 092-2050-00 - 2011-2012 Diesel, 2011 Lightning/Pup Drum Brake - Right-HGB-BEHD-XX (obsolete)
use part #016-9999-99
$191.99
