2008 ZT - Actuator Bar

2008 ZT - Actuator Bar

The 2008 ZT Actuator Bar plays a critical role in the functionality of your mower, ensuring the proper movement and operation of key components. At BadBoyMowerParts.com, we offer a selection of high-quality Bad Boy Mower Parts, including the Actuator Bar specifically designed for the 2008 ZT. With our Bad Boy Mower Part diagrams, finding the right actuator bar for your mower has never been easier. Whether you're replacing a worn-out part or upgrading your mower's performance, we have the parts you need. Our inventory of Bad Boy Lawn Mower Parts ensures that you get durable and reliable components for your mower. Take advantage of Free Shipping On Orders Over $100 and shop for Bad Boy Parts Online to keep your 2008 ZT mower in great working condition. Trust us for fast service and expert support to maintain your mower’s performance.

Bad Boy Mower Parts Lookup

2008 ZT - Actuator Bar
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
2 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
3 018-5049-00 018-5049-00 - 1/2-13 X 2 Hex Bolts Zinc
$2.99
4 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
5 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
6 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
7 034-5039-00 034-5039-00 - OBSOLETE USE 034-2009-00 (obsolete)
use part #034-2009-00
$18.18
8 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
9 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
10 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
11 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
14 031-7000-00 031-7000-00 - Height Indicator Tab and Collar (See Models Used On For Details)
$11.29
15 028-4020-00 028-4020-00 - Actuator Bar (See Models Used On For Detail)
$66.29
16 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
17 017-7008-00 017-7008-00 - 1" Pillow Block Bearing (See Models Used On For Details)
$21.29
18 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
19 047-6047-00 047-6047-00 - 3 Chain (See Models Used On For Details)
$2.99
20 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
21 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
22 031-0052-00 031-0052-00 - 2007-2011 ZT/CZT Transaxle Neutral Lever
$11.34
